20OT-20ft Open Top Brand NEW Standard Shipping Container
Built for flexible overhead loading
A reinforced open-top design combining convenient cargo access with dependable structural strength.
Open access. Strong construction. Secure transport.
Designed for cargo that needs more access.
Technical Specifications
20ft Open Top Brand New Container
Factory New · Flexible Top Loading · ISO Standard Container
A reliable, never-used 20ft open-top container designed for oversized, tall and bulky cargo that requires crane loading or access from above.
General
●Type: 20ft Open Top Dry Container
●Condition: Brand New (Factory New, Never Used)
●Roof System: Removable Steel Roof Bows with Weatherproof Tarpaulin
●Doors: Standard Double Rear Cargo Doors
●Certification: ISO 1496-1 and CSC Compliant
●Warranty: 5-Year Structural Warranty, Subject to Sales Contract
Dimensions and Capacity
●External (L × W × H): 20' × 8' × 8'6" (6.058 × 2.438 × 2.591 m)
●Internal (L × W × H): 19'4" × 7'8" × 7'10" (5.898 × 2.352 × 2.393 m)
●Door Opening (W × H): 7'8" × 7'6" (2.340 × 2.280 m)
●Open-Top Clearance: 8'6" (2.591 m)
●Cubic Capacity: 1,172 cu ft (33.2 m³)
Weight
●Maximum Gross Weight: 52,910 lbs (24,000 kg)
●Approximate Tare Weight: 5,290 lbs (2,400 kg)
●Approximate Payload Capacity: 47,620 lbs (21,600 kg)
Materials and Construction
●Walls: 2.0 mm Corrosion-Resistant Corten Steel
●Floor: 28 mm Marine-Grade Plywood
●Roof: Removable Steel Frame with Weatherproof Tarpaulin
●Reinforcements: ISO Corner Castings and Steel Lashing Rings
●Paint System: Epoxy Coating with UV and Anti-Corrosion Protection
Applications
●Industrial Machinery
●Long Pipes and Steel Products
●Construction Materials
●Oversized and Over-Height Cargo
●Bulky Industrial Equipment
Specifications are typical and may vary by manufacturer or roof configuration. Final specifications and warranty coverage are subject to the approved technical drawing, sales contract and CSC plate.
Product description
Materials List
| S/N | Name | Description |
|---|---|---|
| 1 | Side Walls | Corrosion-resistant CORTEN steel, typical thickness: 2.0 mm |
| 2 | Roof Bows | Removable steel roof bows supporting the tarpaulin roof system |
| 3 | Roof Cover | Heavy-duty weatherproof tarpaulin with secure fastening system |
| 4 | Floor | 28 mm heavy-duty marine-grade plywood flooring |
| 5 | Door System | Double rear cargo doors with steel locking bars and rubber seals |
| 6 | Lashing Rings | Four or more reinforced steel cargo-securing points |
| 7 | Corner Castings | ISO standard corner fittings for lifting, stacking and transport |
| 8 | Paint System | Marine-grade epoxy coating with UV and anti-corrosion protection |
Certificate
FAQ
What is the typical delivery time?
Delivery time depends on quantity, available stock, roof configuration and container location. Please contact us for the current production or delivery schedule.
What cargo is suitable for an open-top container?
Open-top containers are suitable for machinery, pipes, steel products, construction materials and other tall or bulky cargo that requires crane loading or overhead access.
Can the roof be completely removed?
Yes. The weatherproof tarpaulin and removable steel roof bows can be removed to provide full overhead loading access. Roof configuration may vary by order.
Can I use the container for an SOC shipment?
Yes. The container may be exported as a Shipper's Own Container, subject to carrier acceptance, route requirements and a valid CSC plate.
What certification and warranty are available?
The container is designed to comply with ISO 1496-1 and CSC requirements. A five-year structural warranty is available subject to the confirmed sales contract and warranty terms.
