Hysun Containers
20ft HC high cube Brand New Standard Shipping Container
Factory New · ISO Standard · Ready for Global Supply
20ft HC Brand New Container
Designed with one additional foot of exterior height, this factory-new High Cube container provides increased cargo volume while retaining the compact footprint of a 20ft unit.
EXTERNAL LENGTH
20 ft 6.058 m
CUBIC CAPACITY
37.4 m³ ≈ 1,320 cu ft
MAXIMUM GROSS WEIGHT
30,480 kg 67,200 lbs
Technical Specifications
Built for additional cargo volume
Dimensions & Capacity
External: 6,058 × 2,438 × 2,896 mm
Internal: Approx. 5,898 × 2,352 × 2,698 mm
Capacity: Approx. 37.4 m³ / 1,320 cu ft
Weight & Construction
Maximum Gross: 30,480 kg
Reference Tare: 2,280 kg
Structure: Corrosion-resistant weathering steel
01 · EXTRA HEIGHT
High Cube Design
Approximately 305 mm taller externally than a standard-height 20GP container.
02 · DURABILITY
Factory-New Structure
New steel structure, cargo doors, seals and flooring prepared for dependable service.
03 · FLEXIBILITY
Multiple Applications
Suitable for general cargo, secure storage, equipment and conversion projects.
Dimensions and weights shown are reference values. Final specifications are subject to the approved technical drawing, production batch and CSC plate.
Technical Specifications
20ft HC Brand New Container
Factory New · 25G1 High Cube Dry Freight Container
A never-used High Cube dry container designed to provide increased internal height and cargo volume without increasing the standard 20ft footprint.
General
●Type: 20ft High Cube General Purpose Dry Container
●Condition: Brand New (Factory New, Never Used)
●ISO Size/Type Code: 25G1
●Doors: Standard Double Rear Cargo Doors
●Weather Protection: Wind and Watertight
Dimensions and Capacity
●External: L 6,058 mm × W 2,438 mm × H 2,896 mm
●Internal: Approx. L 5,898 mm × W 2,352 mm × H 2,698 mm
●Door Opening: Approx. W 2,340 mm × H 2,585 mm
●Internal Capacity: Approx. 37.4 CU.M / 1,320 CU.FT
Reference Weight
●Maximum Gross Weight: 30,480 kg / 67,200 lbs
●Reference Tare Weight: 2,280 kg / 5,027 lbs
●Reference Payload: 28,200 kg / 62,170 lbs
Construction
●Structure: Corrosion-resistant weathering steel
●Floor: 28 mm heavy-duty plywood flooring
●Corners: ISO standard corner castings
●Finish: Protective marine-grade coating system
Applications
●International Shipping
●Secure Commercial Storage
●Lightweight or High-Volume Cargo
●Container Conversion Projects
Specifications are reference values and may vary by manufacturer or production batch. Final values are subject to the approved technical drawing and CSC plate.
Product description
20HC Technical Specifications
| External Dimensions (L × W × H) |
L 6,058 mm × W 2,438 mm × H 2,896 mm (20ft × 8ft × 9ft 6in) |
Internal Dimensions (L × W × H) |
Approx. L 5,898 mm × W 2,352 mm × H 2,698 mm |
| Door Opening (W × H) |
Approx. W 2,340 mm × H 2,585 mm | Internal Capacity | Approx. 37.4 CU.M / 1,320 CU.FT |
| Reference Tare Weight | 2,280 kg / 5,027 lbs | Maximum Gross Weight | 30,480 kg / 67,200 lbs |
Reference configuration only. Final dimensions and weights are subject to the approved technical drawing and CSC plate.
Materials List
Structural Material Specifications
| S/N | Name | Description |
|---|---|---|
| 1 | Corner Casting | ISO standard corner fitting, reference size 178 × 162 × 118 mm |
| 2 | Floor Beam – Long Side | CORTEN A steel, reference thickness 4.0 mm |
| 3 | Floor Beam – Short Side | CORTEN A steel, reference thickness 4.5 mm |
| 4 | Floor | 28 mm heavy-duty plywood flooring |
| 5 | Corner Column | CORTEN A steel, reference thickness 6.0 mm |
| 6 | Rear Inner Column | SM50YA steel with channel-steel reinforcement |
| 7 | Long-Side Wall Panels | CORTEN A steel, reference panel thickness 1.6–2.0 mm |
| 8 | Front Wall Panels | CORTEN A steel, reference thickness 2.0 mm |
| 9 | Door Panels | CORTEN A steel, reference thickness 2.0 mm |
| 10 | Door Header Beam | CORTEN A steel, reference High Cube thickness 4.0 mm |
| 11 | Door Locking System | Four container locking bars |
| 12 | Top Beam | CORTEN A steel, reference thickness 4.0 mm |
| 13 | Roof Panel | CORTEN A steel, reference thickness 2.0 mm |
Material grades and thicknesses are typical construction references and may vary by factory, production design and approved order specification.
Certificate
FAQ
What is the typical delivery time?
Delivery time depends on available stock, order quantity, color requirements and production schedule. The confirmed schedule will be stated in the official quotation.
Can this container be used for an SOC shipment?
Yes, subject to carrier acceptance, route requirements and confirmation of the container’s valid CSC plate and shipping documents.
What is the advantage of a 20HC container?
A 20HC retains the compact 20ft footprint while providing approximately 305 mm of additional exterior height and around 37.4 m³ of internal capacity.
How are complete containers transported?
Complete units are normally transported by container vessel, truck or rail. One-way and SOC arrangements may be available depending on the route.
What documents and payment terms are available?
Applicable technical documents and CSC information can be provided with the order. Payment terms and validity are confirmed in the official quotation or proforma invoice.
